Non-metal Plate Laser Cutting Machine, CMA1325C-B-A
Applicable materials
Wood board, plywood, medium-density fiberboard, acrylic plate and other large-format non-metal plates
Technical Parameter
| Model | CMA1325C-B-A |
| Laser power (W) | 80~150 |
| Working area (mm) | 1300×2500 |
| Overall dimension (mm) | 3530x1850x1150 |
| Weight (kg) | 600 |
| Position accuracy (mm) | ±0.01 |
| Reposition accuracy (mm) | ±0.05 |
| Maximum speed (m/min) | 25 |
| Power supply | 220V/50Hz |
| Working environment | Temp: 5~ 40°C Humidity: 5-80% No condensate water, no dust or less dust. |
Samples:
Product Feature
1. Equipped with a reinforced welded lathe bed and a finish milling processed large gantry. The non-metal laser cutting machine is annealed and processed using vibration aging technology to relieve stress and control the deformation deviation within ±0.02mm.
2. High-strength aluminum alloy gantry features lighter weight, smaller resonance and smoother operation compared to traditional steel beams.
3. Perfect for cutting density board, acrylic plate and other non-metal plates.
